Clawperator Snapshot Format

This is the dedicated reference page for the structure returned by Clawperator snapshot surfaces.

Use this page as the source of truth for:

  • snapshot_ui result payloads
  • clawperator observe snapshot
  • the hierarchy_xml UI tree format
  • how snapshot fields relate to NodeMatcher

Contract summary

snapshot_ui and clawperator observe snapshot use the same internal pipeline and return the same canonical snapshot format: hierarchy_xml.

On success:

  • data.actual_format is always "hierarchy_xml"
  • data.text contains the XML hierarchy as a string
  • data.foreground_package may identify the active app package
  • data.has_overlay reports whether Clawperator detected a higher-priority accessibility window above the foreground app
  • data.overlay_package may identify that overlay window's package when known
  • data.window_count reports how many accessibility windows were visible during capture

The Android runtime emits the hierarchy dump, and the Node layer attaches that raw XML into the result envelope after execution.

Important: raw snapshot presence does not always mean the node is currently fully on-screen. Some Android views include clipped or off-screen descendants in the hierarchy dump, especially inside large scroll containers.

Important: overlay metadata is best-effort accessibility-window metadata, not a guaranteed modal detector. Agents should use it as an operational hint, then confirm with the XML tree, screenshots, or a follow-up action.

Relationship to Android UI Automator

Clawperator's snapshot structure is modeled after Android UI Automator output, so the overall shape should feel familiar to agents and developers who have used UI Automator dumps before.

It is not a byte-for-byte copy.

Agents should assume:

  • the high-level hierarchy and common node attributes are intentionally similar
  • Clawperator wraps the snapshot inside its own execution result envelope
  • Clawperator may normalize surrounding metadata and matching guidance
  • Clawperator-specific semantics such as NodeMatcher.role are not direct copies of raw UI Automator fields

Use UI Automator knowledge as a mental model, not as an exact parser contract.

Envelope placement

Example request:

{
  "deviceId": "<device_id>",
  "execution": {
    "commandId": "cmd-snap-1",
    "taskId": "task-snap-1",
    "source": "local-test",
    "expectedFormat": "android-ui-automator",
    "timeoutMs": 30000,
    "actions": [
      { "id": "snap1", "type": "snapshot_ui" }
    ]
  }
}

Example success response:

{
  "ok": true,
  "envelope": {
    "commandId": "cmd-snap-1",
    "taskId": "task-snap-1",
    "status": "success",
    "stepResults": [
      {
        "id": "snap1",
        "actionType": "snapshot_ui",
        "success": true,
        "data": {
          "actual_format": "hierarchy_xml",
          "foreground_package": "com.android.settings",
          "has_overlay": "false",
          "window_count": "2",
          "text": "<?xml version=\"1.0\" encoding=\"UTF-8\"?><hierarchy rotation=\"0\">...</hierarchy>"
        }
      }
    ],
    "error": null
  },
  "deviceId": "<device_id>",
  "terminalSource": "clawperator_result"
}

Failure case:

  • if post-processing completes without attached hierarchy text, the step returns success: false with data.error: "SNAPSHOT_EXTRACTION_FAILED"

Troubleshooting for that case lives in Troubleshooting the Operator App.

hierarchy_xml

Each <node> represents one UI element.

The XML is close to Android UI Automator hierarchy output, but Clawperator docs define how agents should interpret the fields for this product.

XML attribute NodeMatcher field Notes
resource-id resourceId "com.example.app:id/name". Empty string when not set by developer.
text textEquals / textContains Visible text content. Empty string if none.
content-desc contentDescEquals / contentDescContains Accessibility label. Empty string if none.
class - Java widget class name. Informational only. NodeMatcher.role uses Clawperator semantic role names, not the raw class string.
clickable - "true" if the element accepts tap events.
scrollable - "true" marks a scroll container.
bounds - "[x1,y1][x2,y2]" pixel rectangle. Useful for spatial layout.
enabled - "false" means visible but not interactable.
long-clickable - "true" if the element accepts long-press.

Snapshot metadata fields

These fields live alongside data.text in successful snapshot_ui step data.

Envelope field Meaning Notes
actual_format Snapshot format identifier Always "hierarchy_xml" today.
foreground_package Package name of the active root window Best-effort. Usually the app the agent is currently operating.
has_overlay Whether Clawperator detected another meaningful accessibility window above the foreground app String value "true" or "false". Treat as a hint, not a hard blocker verdict.
overlay_package Package name of the detected overlay window Present only when Clawperator can identify it.
window_count Number of accessibility windows visible at capture time Informational. Android can report more than one window during normal operation.
text Raw XML hierarchy dump The canonical tree content.

Parsing guidance

What to rely on most

When building selectors, prefer:

  1. resource-id
  2. content-desc
  3. exact text
  4. substring matching
  5. semantic role

Important differences from raw UI Automator assumptions

  • NodeMatcher.role is a Clawperator semantic layer, not the raw class attribute.
  • Snapshot content is carried in data.text inside the result envelope, not as a standalone dump file.
  • Agents should reason over both the XML tree and the execution envelope, not just the XML alone.
  • Some screens include descendants that are technically present in the raw XML but are still clipped outside the current viewport. Treat bounds, clickability, and follow-up actions such as wait_for_node or scroll_until as the operational truth for what is actually reachable.
  • has_overlay: "true" means Clawperator saw another meaningful accessibility window, not necessarily that interaction is impossible. System dialogs, permission prompts, chooser sheets, keyboards, and OEM overlays may all surface this signal.
  • window_count > 1 does not by itself mean an overlay is blocking progress. Android often reports multiple windows even on healthy screens.

XML escaping

Snapshot output is XML, so special characters in attribute values are escaped. For example:

  • apostrophe becomes &apos;
  • ampersand becomes &amp;

These escaped sequences are returned as-is in data.text.

For a node with content-desc="Search for &apos;vlc&apos;":

  • contentDescContains: "Search for" works
  • contentDescEquals: "Search for 'vlc'" fails because the apostrophe is not decoded after extraction

Annotated live-device example

The example below is preserved from a real Android Settings capture and should remain the canonical example unless replaced with a better real-device sample.

<hierarchy rotation="0">
  <node index="0" text="" resource-id="" class="android.widget.FrameLayout"
        package="com.android.settings" content-desc=""
        clickable="false" enabled="true" scrollable="false"
        bounds="[0,0][1080,2340]">
    ...
        <!-- Scrollable list. Use as 'container' in scroll_and_click, scroll, or scroll_until -->
        <node index="0" text="" resource-id="com.android.settings:id/recycler_view"
              class="androidx.recyclerview.widget.RecyclerView"
              package="com.android.settings" content-desc=""
              clickable="false" enabled="true" focusable="true" scrollable="true"
              bounds="[0,884][1080,2196]">

          <!-- Icon-only button. No text, so target via content-desc -->
          <node index="0" text="" resource-id="" class="android.widget.Button"
                package="com.android.settings" content-desc="Search settings"
                clickable="true" enabled="true" focusable="true"
                bounds="[912,692][1080,884]" />

          <!-- Clickable row. The LinearLayout is the tap target -->
          <node index="2" text="" resource-id="" class="android.widget.LinearLayout"
                package="com.android.settings" content-desc=""
                clickable="true" enabled="true" scrollable="false"
                bounds="[30,1252][1050,1461]">
            <!-- Title label with stable resource-id -->
            <node index="0" text="Connections" resource-id="android:id/title"
                  class="android.widget.TextView" package="com.android.settings"
                  content-desc="" clickable="false" enabled="true"
                  bounds="[216,1294][507,1364]" />
            <!-- Subtitle label -->
            <node index="1" text="Wi-Fi  •  Bluetooth  •  SIM manager"
                  resource-id="android:id/summary" class="android.widget.TextView"
                  package="com.android.settings" content-desc=""
                  clickable="false" enabled="true"
                  bounds="[216,1364][816,1419]" />
          </node>

          <node index="3" text="" resource-id="" class="android.widget.LinearLayout"
                package="com.android.settings" content-desc=""
                clickable="true" enabled="true" scrollable="false"
                bounds="[30,1461][1050,1721]">
            <node index="0" text="Connected devices" resource-id="android:id/title"
                  class="android.widget.TextView" package="com.android.settings"
                  content-desc="" clickable="false" enabled="true"
                  bounds="[216,1503][661,1573]" />
            <node index="1" text="Quick Share  •  Samsung DeX  •  Android Auto"
                  resource-id="android:id/summary" class="android.widget.TextView"
                  package="com.android.settings" content-desc=""
                  clickable="false" enabled="true"
                  bounds="[216,1573][996,1679]" />
          </node>

        </node>
    ...
  </node>
</hierarchy>

Reading patterns

  • Tap targets are often clickable="true" container nodes whose child labels hold the visible text.
  • Icon-only buttons often have empty text and rely on content-desc.
  • Scroll containers expose scrollable="true".
  • Disabled elements have enabled="false" and usually require state change before interaction.

Apps with weak or missing resource IDs

Many production apps leave resource-id="" on most nodes. In those cases, fallback priority is:

  1. contentDescEquals
  2. textEquals
  3. contentDescContains or textContains
  4. role: "textfield" for text inputs without stable IDs

When labels contain dynamic values, counts, or escaped characters, prefer substring matching over exact equality.
